Metric |
American |
|
Lifting Capacity |
4000kg |
9000lbs |
|
Min. Height |
100mm |
3-15/16" |
|
Max. Lifting Height |
1850mm |
72-27/32" |
|
Overall Height |
3660mm |
144-3/32" |
|
Overall Width |
3280mm |
129-1/8" |
|
Width between Posts |
2780mm |
109-7/16" |
|
Short Arm Length |
710~1050mm |
27-31/32"~41-11/32" |
|
Long Arm Length |
760~1200mm |
29-15/16"~47-1/4" |
|
Lifting/Lowering Time |
55Sec./45Sec. |
55Sec./45Sec. |
|
Motor Power |
2.2kW |
2.2kW |
|
Power Supply |
220V/50Hz/1Ph 380V/50Hz/3Ph |
220V/60Hz/1Ph 110V/60Hz/1Ph |
