HC8950 | Truck Tyre Changer
♦ Electro-hydraulic, universal and automatic tyre changer for truck, bus, tractor, agricultural and earth moving equipment tyres from 14" to 56".
♦ Super-duty electric motor and hydraulic drive for superior torque and wheel holding power.
♦ Simple controls and positionable unit console lets the operator safely monitor the tire-changing process from the most advantageous angle.
♦ Hydraulically operated universal self-centering chuck clamps rims from 14" to 56" either on the inside or through the center hole ensures clamping of virtually all rims and off-load style wheels.
♦ Hydraulic sled carriage for positioning, bead loosening, mounting and demounting procedures.
♦ Simultaneous movement of chuck carrier and tool holding arm speeds up true handling time.
♦ Manual controlled tool rotation.
♦ The clamping chuck rotates in both direction and at two different speeds.
♦ With pressure gauge for monitoring the hydraulic pressure.
Technical Data Details Overall Dimension Optional parts

Rim Clamping Range

14"~46"

Rim Clamping Range with Adaptor

Up to 56"

Max. Wheel Diameter

2300mm

Max. Wheel Weight

1500kg

Max. Wheel Width

1065mm

Operating Pressure

130 bar

Bead Breaking Force

3,500kg

Gear Motor Power

1.5kW

Power Supply

380V/50Hz/3Ph

220V/50Hz/1Ph
