Metric |
American |
|
Lifting Capacity |
3500kg |
7700lbs |
|
Min. Height |
110mm |
4'3/8" |
|
Max. Lifting Height |
1920mm |
15-5/8" |
|
Platform Length |
1450mm |
57-1/16" |
|
Platform Width |
650mm |
25-5/8" |
|
Distance between Platforms |
820mm |
32-1/4" |
|
Air Supply |
6~8kg/cm² |
85~113.6 psi |
|
Lifting/Lowering Time |
55 Sec./45 Sec. |
55 Sec./45 Sec. |
|
Motor Power |
2.2kW |
2.2kW |
|
Power Supply |
220V/50Hz/1Ph 380V/50Hz/3Ph |
220V/60Hz/1Ph 110V/60Hz/1Ph |
