Metric |
American |
|
Lifting Capacity |
4,000kg |
9000lbs |
|
Min. Height |
147mm |
5-13/16" |
|
Max. Lifting Height |
2,220mm |
87-7/16" |
|
Overall Length |
5782.5mm |
227-11/16" |
|
Overall Width |
3,341mm |
131-1/2" |
|
Overall Height |
2,456mm |
96-11/16" |
|
Runway Length |
4790mm |
188-9/16" |
|
Runway Width |
508mm |
20'' |
|
Width between Posts |
2,484mm |
97-13/16" |
|
Width between Platforms |
994mm |
39-1/8" |
|
Lifting/Lowering Time |
50 Sec./35 Sec. |
55 Sec./45 Sec. |
|
Motor Power |
2.2kW |
2.2kW |
|
Power Supply |
380V/50Hz/3Ph 220V/50Hz/1Ph |
220V/60Hz/3Ph 110V/60Hz/1Ph |
