Metric |
American |
|
Lifting Capacity |
3,600kg |
8,000lbs |
|
Min. Height |
125mm |
4-15/16'' |
|
Max. Lifting Height |
2100mm |
86" |
|
Overall Length |
5,748.5mm |
226-5/16'' |
|
Overall Width |
2942mm |
115-13/16'' |
|
Overall Height |
2476mm |
97-1/2'' |
|
Runway Length |
4699mm |
185'' |
|
Runway Width |
508mm |
20'' |
|
Width between Posts |
2221mm |
87-7/16'' |
|
Width between Platforms |
970mm |
38” |
|
Lifting/Lowering Time |
50 Sec./35 Sec. |
55 Sec./45 Sec. |
|
Motor Power |
2.2kW |
2.2kW |
|
Power Supply |
380V/50Hz/3Ph 220V/50Hz/1Ph |
220V/60Hz/3Ph 110V/60Hz/1Ph |
