HFL4340X |
America |
|
Lifting Capacity |
6500kg |
14,330lbs |
|
Min. Height |
191mm |
7.5-3/4" |
|
Max. Lifting Height |
1,800mm |
71-3/4" |
|
Overall Length |
7,040mm |
277" |
|
Overall Width |
3,575mm |
141-1/2" |
|
Overall Height |
2,254mm |
89-1/2" |
|
Runway Length |
5,770mm |
227-3/8" |
|
Runway Width |
508mm |
20" |
|
Width between Posts |
2,895mm |
11" |
|
Width between Platforms |
1,080~1,180mm |
42~46-5/16" |
|
Lifting/Lowering Time |
50 Sec./35 Sec. |
50 Sec./35 Sec. |
|
Motor Power |
3.0kW |
2.2kW |
|
Power Supply |
220V/50Hz/1Ph 380V/50Hz/3Ph |
220V/60Hz/3Ph 110V/60Hz/1Ph |
